• An ISO 9001:2015 Certified Company

Enquark House-wire

Multi Strand House Wires

Enquark produces the best standard house wires with the quality in PVC and Copper strands thickness. The wires are available in different thickness and sizes which are 0.75 mm (green colour) , 1 mm (red, black, blue and yelllow colour), 1.5 mm (red, black, blue and yelllow colour), 2.5 mm (red and black colour), 4 mm (red and black colour), 6 mm (red and black colour). The Enquark products are available and can be purchased from local retailers and distributors across India. The products are also available on the leading e-commerce portals like Amazon and Flipkart. Enquark has set-up a world class quality check laboratory for the validation of all products before forwarding it to the market for sales. Enquark is an ISO 9001, ROHS, CE compliant and certified company. We focus on safety through out the product lifecycle and following value chains like designing, developing, quality checking and distribution, installation and consumption.

HRFR (Halogen-Free Fire Retardant)

Enquark uses high-quality PVC materials for insulation, which produce low smoke and very low toxic gases.

Higher Current Carrying Capacity

Enquark Green electric wires are made of 99.96 % pure copper with cutting-edge technology that delivers 23-25% higher current.

Higher Flexibility

Enquark Wires are made with copper multi-strands of uniform thickness with double-coated PVC insulation.

Flame Retardant (FR)

Enquark Wires are produced using premium PVC, which gives them greater stability and flame resistance.

How It’s Work

How to Choose the Best House Wire

Many businesses in India produce and market electrical wires and cables, but not every wire or cable that is offered on the market is ideal for your home. Many different factors affect wire quality. Please take into account the following factors before purchasing to determine the best quality wire for your home wiring.

Step

01

Sizes of the Conductor

When evaluating the wires' quality, the conductor's size should be given the utmost consideration. Low gauge wire cannot provide the required current capacity. Therefore, before making a purchase, verify the gauge of your wires. There are many variations in gauge sizes of wires in the market. Make sure you are purchasing full-gauge wire following BIS standards.

Step

02

Purity of Copper

Regarding determining the quality of wires, copper purity is also a crucial factor. Enquark reduces energy consumption and electricity costs by using CC-grade copper, which is 99.96 % pure. Many businesses use low-grade copper, which has a high resistance value and high energy loss.

Step

03

The quality of insulation

The fire protection of wires is significantly impacted by the quality of PVC materials used in the insulation coating. Enquark uses PVC materials that are fire retardant (FR) and halogen-free flame retardant (HFFR), which have excellent fire retardant properties at high temperatures, for insulation with double-layer protection. However, a lot of the wires that are currently on the market lack such high-quality insulation, making them much more explosive.

Enquark Notice

Why It's Important to Choose the Best Size Wire

Our prime focus is "People’s Safety" within our organisation and for all consumers. We stand for "Be Safe Ever..." as our business tagline because safety does not come with luck, rather we have to prepare for it.

Electrical safety and cost-effectiveness both depend greatly on selecting the right size of electric wire. You are likely wasting money on too much metal if you choose too large a wire size because doing so will only increase your costs without offering you any benefits. A high current in a small-diameter wire increases resistance. Moreover, high resistance will produce high heat, which can burn the surroundings due to fire. Therefore, you will suffer a significant loss as a result of the fire. Always select high-quality wire in the appropriate size for your needs. Enquark house wire considers all these factors, and that is a perfect choice for your home.

Enquark Housewire Size Chart

Nominal area of conductor SQ.mm. Maximum diameter of each strand Thickness of Insulation (Nom) mm. Approx Overall Diameter in mm. Curent Carrying Capacity Rating Amps(') Resistance (max) per km @20C Ohms
0.75 24/0.21 0.6 2.5 7 26
1 14/0.31 0.7 2.8 12 18.1
1.5 22/0.30 0.7 3.1 16 12.1
2.5 36/0.30 0.8 3.8 22 7.41
4 56/0.30 0.8 4.4 29 4.95
6 84/0.30 0.8 5.2 37 3.3
10 80/0.41 1.0 5.8 51 1.91
16 126/0.40 1.0 6.8 68 1.21

RoHS Compliance

RoHS Requirement
Contents Values
CADMIUM(Cd) CONTENT Max 100 ppm
LEAD(pb) CONTENT Max 1000 ppm
MERCURY(Hg) CONTENT Max 1000 ppm
CHROMIUM(VI) CONTENT Max 1000 ppm
RoHS Requirement from Brominated
flame retardants POLLY
BROMINATED BIPHENYLS (PBBs)
Max 1000 ppm
